High resolution PAL/NTSC 100m IR distance CCD CCTV Surveillance Camera with OSD,27x Auto Lens AS-869 manufacturer from China Hongkong Angels Security Electric Co.,Ltd.

Place of Origin:

Guangdong, China (Mainland)

Product Detail

Model No.: AS-869

Sensor: 1/4"color CCD,1/3"color CCD...

Scanning system: 2:1 interlace

Day/night: auto

Infrared LED: 8pcs dock-glass IR Lights +...

Delivery Date: 7 days

TV system: PAL/NTSC

Minimum illumination: 0 lux (IR on)

Backlight compensation: auto

IR distance: 100 meters

High resolution PAL/NTSC 100m IR distance CCD CCTV Surveillance Camera with OSD,27x Auto Lens

Image Sensor: Sony 1/3"color CCD

TV system: PAL/NTSC

Scanning system: 2:1 interlace

Synchronize system: internal

Minimum illumination: 0 lux (IR on)

S/N ratio: ≥48dB

Video output: 1.0Vp-p, 75II composite, BNC x 1

Gamma ratio: ≥0.45

Focal length: 27X auto lens

Viewing angle: Vertical: 92°/53°

Day/night: auto

Backlight compensation: auto

White balance: auto

Gamma characteristic: ≥0.15

Electronic shutter:PAL: 1/50 to 1/100,000 seconds

NTSC: 1/60 to 1/100,000 seconds

Infrared LED: 8pcs dock-glass IR Lights + 8pcs F8 IR Light

IR distance: 100 meters

Infrared spectrum: 850nm

Operating temperature: -10 to +50°C

Storage temperature : -40 to +60°C

Vandal-proof casing: IP66

Input voltage/current: DC 12V/500mA

Serial products:

AS-8495	Sony 1/4 CCD,420TVL,0LUX(With IR On), 8pcs dock-glass IR Lights +8pcs F8 IR Lights, 100m distance, 27X auto lens (Without Bracket)
AS-8497	Sony 1/3 CCD,650TVL,0LUX(With IR On), 8pcs dock-glass IR Lights +8pcs F8 IR Lights, 100m distance, 27X auto lens (Without Bracket)
