PAL/NTSC IR Dome Camera with Night Vision Function, BLC and AGC Function, AL Casing/Strong and Beautiful manufacturer from China Hongkong Angels Security Electric Co.,Ltd.

Payment Terms:	T/T
Place of Origin:	Guangdong, China (Mainland)

Product Detail

Means of Transport: Ocean,Air

Sensor: 1/4"color CCD,1/3"color CCD...

Scanning system: 2:1 interlace

White balance: automatic

Lens: f = 6mm

Delivery Date: 7-30 days

TV system: PAL/NTSC

AGC: automatic

BLC: automatic

PAL/NTSC IR Dome Camera with Night Vision Function, BLC and AGC Function, AL Casing/Strong and Beautiful

Image Sensor: Sharp or Sony 1/4"color CCD,1/3"color CCD, CMOS

TV system: PAL/NTSC

Scanning system: 2:1 interlace

Synchronize system: internal

Horizontal synchronize frequency: 15.625 to 15.734kHz

Vertical synchronize frequency: 50 to 60Hz

Video output: 1.0vp-p, 75ohm

Gamma consumption: 0.45

AGC: automatic

S/N ratio: better than 48dB

White balance: automatic

Electronic shutter: 1/60 (NTSC)/1/50 (PAL) to 1/10,000 seconds

BLC: automatic

Power supply: 12V DC

Operating temperatures: -20 to 70°C, RH 95% maximum

Storage temperatures: -40 to 85°C, RH 95% maximum

Lens: f = 6mm

AS-8323	Sharp1/4 CCD,420TVL,0LUX(With IR on), 24pcs F5 IR Lights, 25m distance, 6mm Lens
AS-8324	CMOS,420TVL,0LUX(With IR on), 24pcs F5 IR Lights, 25m distance, 6mm Lens
AS-8325	Sony1/4 CCD,420TVL,0LUX(With IR on),24 pcs F5 IR Lights, 25m distance, 6mmLens
AS-8326	Sony 1/3CCD,420TVL,0LUX(WithIR on), 24pcs F5 IR Lights, 25m distance, 6mm Lens
AS-8327	Sony1/3 CCD,480TVL,0LUX(WithIR on), 24pcs F5 IR Lights, 25m distance, 6mm Lens
AS-8328	Sony1/3 CCD,600TVL,0LUX(WithIR on),OSD,24 pcs F5 IR Lights, 25m distance, 6mm Lens
AS-8329	Sony1/3 CCD,650TVL,0LUX(WithIR on),OSD,24 pcs F5 IR Lights, 25m distance, 6mm Lens
AS-83210	Sony1/3 CCD,700TVL,0LUX(WithIR on),OSD,24 pcs F5 IR Lights, 25m distance, 6mm Lens
